C4D对称固定插件 SymmetryClamp v1.1

2015-10-25 22:51 发布 | 作品版权归原作者所有，仅供参考学习，禁止商业使用！

插件脚本 /[系统辅助]

C4D对称固定插件 SymmetryClamp v1.1
C4D对称固定插件 SymmetryClamp v1.1 - C4D之家 - cinema4d_ 2015-10-25 22.47.44.jpg

Installation:

[All versions]
Close Cinema 4D.
Unzip the 'SymmetryClamp1-1' folder into the Cinema 4D 'plugins' folder.

[R9.1]
The 'Symmetry Clamp 1-1.c4d' file inside the 'SymmetryClamp1-1' folder contains the tag
connected to its User Data and applied to an object.
This setup must be loaded in order to use the plugin.
Note: Symmetry Clamp has been created using the R9.5 SDK. It is recommended that the plugin
be used with R9.5 or higher.

[R9.5 and R9.6]
Open the 'Symmetry Clamp 1-1.c4d' file inside the 'SymmetryClamp1-1' folder.
In Cinema 4D, click on the Symmetry Clamp 1.1 tag.
From the Edit menu in the Attributes Manager, select Set As Default.
Tag settings can also be saved from the Object Manager using File > Save Tag Preset.
The tag can also be dragged to and loaded from the Content Browser.

[R10]
Open the 'Symmetry Clamp 1-1.c4d' file inside the 'SymmetryClamp1-1' folder.
A bug in R10 prevents the saving of tag settings via the Attributes Manager (ver R10.008).
In Cinema 4D, click on the Symmetry Clamp 1.1 tag.
The tag settings can be saved from the Object Manager using File > Save Tag Preset.
The tag can also be dragged to and loaded from the Content Browser.
The tag should be set up with Lock Zero Points unchecked as default. After applying a
tag and aligning zero points, remember to check Lock Zero Points before beginning
constrained-point editing.
If removing Symmetry Clamp 1.0, tag presets can be deleted via the Content Browser.

Usage:

When Lock Zero Points is unchecked, all points can be moved freely.
When Lock Zero Points is then checked, any points currently at zero on the Mirror Plane's
perpendicular axis will be constrained.
Any points subsequently moved to zero will remain unconstrained until:
* Lock Zero points is unchecked and then checked again; or
* the point count of the object changes.
A centre poly perpendicular to the Mirror Plane will always be grouped with its mirrored
poly when extruded. A non-perpendicular poly will be grouped with its twin when Lock Zero
Points is checked and will be extruded separately when Lock Zero Points is unchecked.
When Lock Zero Points is checked, zero points will remain constrained when the mesh object
is moved, rotated or scaled.

Thanks to:

Matthias Bober for integrating the expression into a plugin tag and
creating the tag icon;
tcastudios for bug reports and coding assistance; and
Lorenzo de Trizio (aka MrBraun) for bug reports and feature requests.

Copyright and Disclaimer:

Symmetry Clamp ?007 David Wickenden
Symmetry Clamp is distributed as-is and no warranties are given.
I will not accept liability for any damage or loss of data resulting from the use
of this plugin.
This plugin is free for personal and commercial work.
